English
53
HDbaseT control function table
Control
Side
Function
Standby Mode
Remark
Eco
(< 0.5W)
Network
(<2W)
Normal
(>2W)
Projector
Front-IR
(Wireless)
O O
O (Can disable
by OSD)
Rear-IR
(Wireless)
O O
O (Can disable
by OSD)
RS-232 O O X
RJ45/LAN X O X
Wired Remote O O O
HDBaseT TX Box
HDBT-IR
(Wireless)
X X O
RS-232 X X O
RJ45/LAN X X O
Wired Remote X X O
User can connect wired
remote at HDBaseT TX side
to get the wired function.
O: Enable X: Disable
• Baud Rate
Press
◄
/
►
to select RS-232 baud rate. The rate is xed at 9600 for HDBaseT mode. The
baud-rate option is only available when a 9-pin RS-232 connector is in use.
• Test Pattern
Press
◄
/
►
to select the test pattern. The options are Off, Grid, White, Red, Green, Blue,
Black, RGB Ramps, Color Bar, Step Bars, CheckBoard, Horizental Lines, Vertical Lines,
Diagonal Lines, Horizontal Ramp and Vertical Ramps.
• Image Memory
To enable users to save and apply a set of image settings customized for regularly used
circumstance by source and timing
• 12V Trigger
Press
◄
/
►
to enable or disable 12V trigger function.
• Standby Settings
Press ENTER to enter the Standby Settings menu. See "Standby Settings menu" on
page 56 for more details.
• Network Settings
Press ENTER to enter the Network Settings menu. See "Network Settings menu" on
page 56 for more details.
• Reset All Settings
Press ENTER to reset all settings to default value.
