Instruction Manual
1717
4.2.2 Magnetic fields
AVOID exposing the flowmeter to strong or nearby magnetic fields.
Fig. 6 Avoid magnetic fields
4.2.3 Negative pressure
Avoid vacuum conditions in the pipe. They can damage the coating of the flowmeter and move the electrodes
from their correct position.
4.2.4 Protection from direct sunlight
Protect the flowmeter if exposed to direct sunlight.
Fig. 7 Avoid direct exposure to sunlight
4.2.5 Operating temperatures
For normal and ecient operating of the flowmeter:
The ambient temperature must be limited within the range of (-25 ÷ +60) °C, (-13 ÷ +140) °F.
Fig. 8 Environment and fluid temperature limits
The process temperature must be limited within the range of (0÷ +80) °C, (32 ÷ +176) °F.
N S
