Bernette Airlock b64 - Preparing the Thread Guide; Attaching the Spool Stabilizer

Setting up the machine
23
2020-09 EN 5040064.00A.04
Preparing the Thread Guide
The Thread Guide ensures a clean unwinding of the thread from the thread cones. Each thread is guided
through a Thread Guide Wire located directly above the thread cone.
> To attach the Retractable Thread Guide, insert it into the opening provided in the Thread Stand until it
clicks.
> Hold the Thread Guide and pull it up to the stop.
> Turn the Thread Guide to the left and right until the two positioning pins engage.
– The outer Thread Guide Wires are parallel to the machine front.
> When not in use, retract the Thread Guide with a little pressure downwards.
Attaching the spool stabilizer
For large thread cones, the spool stabilizer serves to stabilize the thread cone on the spool pin.
> For extremely conical spools, place the spool stabilizer onto the spool pin with the pointy end up.
> For slightly conical spools, place the spool stabilizer onto the thread spool pin with the pointy end down.
