Machine settings
43
2020-09 EN 5040064.00A.04
6 Machine settings
6.1 Setting the knife
Knife On/Off
For a better overview and better access in the sewing area, e.g. for threading, the knife can be lowered (off)
and then engaged again (on). The knife is also lowered if the sewing project already has a clean cut edge
and the edge is only to be finished. The best sewing results are achieved by cutting and finishing in one
single step.
Knife Off (lowered)
> Open the Threader Cover.
> Pull the knife away from the Stitch Plate as far as possible and then lower it forwards to the lock-in
position.
– The knife is lowered.
Knife On (engaged)
> Open the Threader Cover.
> Pull the knife away from the Stitch Plate as far as possible and then lift it backwards to the lock-in
position.
– The knife is engaged.
> Close the Threader Cover.
NOTICE
Finger injury
Before each sewing start make sure that the Knife Cover Insert is attached.
