Appendix
82
2020-09 EN 5040064.00A.04
10.4 Specifications
Designation Value Unit
Number of stitches 16
Number of loopers 2
Number of needles 1 ─ 2
Needle System ELx705
Needle Size 80 ─ 100 (12 ─ 16)
Differential Feed 0.6 ─ 2.0
Maximum fabric thickness 5.3 (0.23) mm (in)
Stitch Length 1.0 ─ 5.0 (0.03 ─ 0.17) mm (in)
Cutting Width Left Overlock Needle LN 5 ─ 7 (0.19 ─ 0.35) mm (in)
Cutting Width Right Overlock Needle RN 3 ─ 5 (0.11 ─ 0.27) mm (in)
Minimum sewing speed 300 Stitches per minute
Maximum sewing speed 1300 Stitches per minute
Dimensions without Retractable Thread Guide 43 x 27 x 29 (16.92/10.62/11.41) cm (in)
Dimensions with Sewing Table / Cut-offs Bin 59 x 40 x 29 (23.22/15.78/11.41) cm (in)
Weight of the machine 9.3 (20.46) kg (lb)
Weight packaged 12.8 (28.2) kg (lb)
Input voltage (energy consumption) 120 (80) / 230 ─ 240 (75) Volt (W)
Protection class (electrical engineering) II
Date of manufacture Visible on the type plate
