Bernette Airlock b64 - Stitch Chart Overview

Stitch
41
2020-09 EN 5040064.00A.04
5.2 Stitch Chart
This manual includes a Stitch Overview with all necessary default settings for each stitch. These default values
may vary depending on the used material.
> Remove all the needles which are not required.
> Set the mtc Micro Thread Control to «-».
No. Stitch name Stitch pattern
No.1 4-thread overlock with Integrated safety
seam
4 4 4 4 6 N 2.5 1
No.2 3-thread super-stretch 5 4 4 6 N 2.5 1
No.3 3-thread overlock wide (LN) 4 ─ 4 4 6 N 2.5 1
No.4 3-thread overlock narrow (RN) ─ 4.5 4 4 6 N 2.5 1
No.5 3-thread flatlock wide (LN) 0 ─ 5 8 5.5 N 2.5 1
No.6 3-thread flatlock narrow (RN) ─ 0 6.5 8 6 N 2.5 1
No.7 3-thread narrow seam ─ 4.5 5 4 6 R 1.5 1
No.8 3-thread rolled hem ─ 4.5 5 7 5 R 1.5 1
No.9 2-thread wrapped overlock wide (LN) 3 ─ 3.5 6 N 2.5 1
No.10 2-thread wrapped overlock narrow (RN) ─ 5 4 6 N 2.5 1
No.11 2-thread flatlock wide (LN) 0,5 ─ 7 5.5 N 2.5 1
