Bernette Chicago 5 - Changing the Presser Foot; Two-Step Presser Foot

18
Machine Setup
Changing the Presser Foot
Two-Step Presser Foot
There are two raising levels of the presser foot. Lifting the foot
up to the first level is used to place the fabric under the foot
for sewing.
The second level is only used in embroidery mode to remove
the hoop easily.
Turn power switch to off («O») when carrying out any of the
following operations!
Attaching the presser foot holder
• Raise the presser foot bar (a).
• Attach the presser foot holder (b) as illustrated.
Attaching the presser foot
• Lower the presser foot holder (b) until the cut-out (c) is
directly above the pin (d).
• Press the black lever (e).
• Lower the presser foot holder (b) and the presser foot
(f) will engage automatically.
Removing the presser foot
• Raise the presser foot.
• Press the black lever (e) and the foot will disengages.
Attaching the edge/quilting guide
• Attach the edge/quilting guide (g) in the slot as illus-
trated.
• Adjust according to the need for hems, pleats, etc.
AtteNtioN!
Note
The needle must always be at the highest position.
a
b
b
d
c
f
e
e
g
