161
Troubleshooting
General Explanation Repair Messages
Incorrect needle for the stitch plate
selected
Needle is not in the highest position
Main motor is not running
No embroidery hoop attached
Embroidery hoop attached
Attaching the Module
Needle position doesn‘t correspond to
center of hoop
█
check settings in securing program
█
turn handwheel
█
check hook system. Remove any thread lint from the hook
area/bobbin case
█
attach embroidery hoop
█
remove embroidery hoop
█
position the module correctly to the sewing computer. Plug
the cable in the outlet provided
█
an animation shows that emboidery software is loaded
Adjust according to User Instructions page 43
Lower feed dog
█
press the «Feed dog»-button. The feed dog is lowered
Upper thread used up
Lower thread indicator has reacted
█
attach new upper thread spool and thread
█
check lower thread and wind if necessary
