Bernina 770 QE - Needle and Stitch Plate; Changing the Needle; Selecting the Needle in the User Interface

Sewing preparation
42
2.10 Needle and stitch plate
Changing the needle
> Raise the needle.
> Switch the machine off and disconnect it from the power supply system.
> Remove the presser foot.
> Loosen the fixing screw of the needle using the screwdriver gray Torx.
> Pull the needle down.
> Hold the new needle with the flat side to the back.
> Insert the needle as far as it will go.
> Tighten the fixing screw of the needle using the screwdriver gray Torx.
Selecting the needle in the User Interface
After having changed the needle, it can be checked whether or not it can be used in combination with the
selected stitch plate.
> Touch the icon «Stitch plate/Needle selection».
> Select the inserted needle.
