Bertolini 316 - Preface; Information and General Rules; Spare Parts; Engine Servicing

43
INDEX
- Information and General Rules ............43
- Explanation of symbols .......................43
- Identification data ................................44
- Overall dimensions ...............................44
- Speed ...................................................44
- Technical data .....................................44
- Flanging implements ............................45
- Controls ...............................................46
- Engine start-up ....................................46
- Engaging gears ....................................46
- Power Take-Off ....................................47
- Diflerential Lock ...................................47
- Handlebars ...........................................47
- Turning the handlebar
for front implements .............................47
- Safety devices
Engine stop ..........................................48
Clutch hook ..........................................48
Power Take-Off Hindrance device ........48
- Electric start .........................................49
- Battery ..................................................49
- Switching off engine.............................49
- Temporary stop of Motorcultivator .......49
- Braking .................................................49
- Re-fuelling ............................................50
- Gearbox oil replacement ......................50
- Tyre pressure ........................................50
- Brake assembling instructions .............51
- Controls and adjustment
Engine ...................................................52
Clutch ...................................................52
Brakes ..................................................52
Differential lock .....................................58
- Rotary Hoe coupling ............................53
- Frontal cutter bar .................................54
- Plougs .................................................55
- Adjustable furrow opener .....................55
- Maintenance ........................................56
- Airborne noise .....................................56
- Handlebar vibration .............................56
- Control and lubrication .......................56
PREFACE
Before using the machine, read
this manual carefully and keep
it at reach for future reference.
The Manufacturer reserves the
right to make modifications,
without prior notice and without
incurring into any sanctions
what-soever, provided that the
main technical and safety features be kept.
INFORMATION
AND GENERAL RULES
SPARE PARTS
You are highly recommended to use only
GENUINE SPARE PARTS. Orders must be
made observing the rules given in the Spare
Parts Catalogue.
ENGINE SERVICING
The regulations for using and servicing the
engine are given in the appropriate booklet,
a copy of which is provided with each
machine.
NOTE
The terms RIGHT and LEFT used in this
manual to locate the various components,
always refer to the normal travel direction of
the machine, that is to the machine seen by
the operator in the driver’s position.
EXPLANATION OF THE SYMBOLS
Brake
control
Travel
direction
Clutch control
Throttle
control
Differential
lock
