BestCode Next Series 8 Technical Manual October 2022 Page 120 of 290
4. Open the Electronics Compartment Door
5. Disconnect the Printhead Cable, Printhead
Coax Cables, Fan Cable, Power supply cable,
LCD Display and Power cables, and Level
Switch cables from the main board.
Be careful to pull coax
connections straight out from
the board. Pulling at an angle
can damage the center pin on
the connector and on the
board.
6. Lift up the power supply
7. Remove the mains power.
