BestCode NExT 86 - Printhead Service Routines; Nozzle Replacement

BestCode Next Series 8 Technical Manual October 2022 Page 131 of 290
Printhead Service Routines
The Next Series 8 CIJ Printer features a self-maintaining, self-cleaning printhead, however manual cleaning is occasionally
required.
Recommended cleaning schedule can be seen here
Nozzle Replacement
Be familiar with proper safety information for handling fluids.
Procedure Time: 5 minutes
1. Remove the 2 drop generator side
mounting screws.
2. Remove the 2 nozzle screws.
3. Remove the nozzle.
