BestCode NExT 86 - Printhead Valve Manifold Replacement

BestCode Next Series 8 Technical Manual October 2022 Page 147 of 290
Printhead Valve Manifold Replacement
Be familiar with proper safety information for handling fluids.
Procedure Time: 2 minutes
1. Remove the 2 Printhead manifold
mounting screws.
2. Lift the Manifold.
3. Remove the 2 valve mounting screws.
4. Remove the tubes from the valve
manifold.
5. Make sure the Valve gasket is in place.
