Calibrate
Modulation
Controls the amount of voltage applied to the
drop generator to produce drops.
See here for normal modulation
values by machine type.
Pressure
Increases or decreases the Pressure Set point.
See here for normal Pressure values
by machine type.
Charge
Increase or decreases the Charge Set point.
See here for normal Charge values by
machine type.
Mod. Frequency
Controls the frequency of the voltage applied to
the drop generator
See here for normal modulation
values by machine type.
Errors
Disables ability for errors to occur while the jet is running. Will only operate in this mode
for 30 minutes.
Enables / Disables the high voltage in the printhead.
Height
Displays the HV Height for the currently printing message.
Phasing
Disables the phasing of the drops. Will only operate in this mode for 30 minutes.
Preview Information
Jet
Off
Pressure
0 PSI, 0 RPS
Phase Point
0
Phase Width
0
Jet Speed
0 m/s
Quality
0%
Phase Threshold
13-39
Viscometer
None
Target
4.5 cP
Actual
0.00 cP, 0.0s
Printhead
0-60C
Electric
0-60C
Jet
On
Pressure
40 PSI, 23 RPS (+/- 5 RPS)
Or
50 PSI, 27 RPS (+/- 5 RPS)
Phase Point
0-16
Phase Width
7-9
Jet Speed
This feature only
accurately measures
when Phase Width
and Point are stable.
Also, the Modulation
must be configured.
See Calibrating the
Modulation
Model
Range (Nozzle Size)
81
22.3 +/- 1.5 m/s (75u)
82, 86, 87, 88,
88SOP, 88FG, 88SS
20.1 +/- 1.5 m/s (65u)
22.3 +/- 1.5 m/s (75u)
88SHS, 88SHSOP
20.6 +/- 1.5 m/s (65u)
88SM
20.3 +/- 1.5 m/s (40u)
88HS1, 88SOPHS1
20.8 +/- 1.5 m/s (65u)
Quality
90-100%
Phase Threshold
13-39
Viscometer
See Status Screen
Target
4.5 cP
Actual
0.0cP, 0.0s
2.5-6.0cP, 45.0-115s
Printhead
0-60C
Electric
0-60C
