BestCode NExT 86 - Page 301

BestCode Next Series 8 Technical Manual October 2022 Page 287 of 290
14. Pull the printhead umbilical air supply line to
the valve through the pump grommet on the
middle wall, and connect to the valve outlet
tube.
15. Connect the Air Dryer pressure transducer to
J26 Air Cooler
Power on the system, login as Technician, then navigate to Service>Tools>Technician>Configure and set the Cooling
Method to Air Cooling.
