BIG ASS FANS Basic 6 - Technical Specifications

WWW.BIGASSSOLUTIONS.COM © 2016 DELTA T CORP. ALL RIGHTS RESERVED.
1
TECHNICAL SPECIFICATIONS
Note: All controllers produce 3-phase output power regardless of input phase.
Basic 6
Diameter Motor Size Minimum Circuit Size Full Load Amps (Fan)
8 ft (2.4 m)
1.0 hp
(0.75 kW)
15 A @ 100–125 V, 1 Φ
15 A @ 200–240 V, 1 Φ
10 A @ 200–240 V, 3 Φ
10 A @ 400–480 V, 3 Φ
10 A @ 575–600 V, 3 Φ
9.0 A
8.8 A
5.0 A
2.6 A
1.3 A
10 ft (3.0 m)
12 ft (3.6 m)
1.5 hp
(1.1 kW)
25 A @ 200–240 V, 1 Φ
15 A @ 200–240 V, 3 Φ
10 A @ 400–480 V, 3 Φ
10 A @ 575–600 V, 3 Φ
13.3 A
5.0 A
2.6 A
2.0 A
14 ft (4.3 m)
16 ft (4.9 m)
2.0 hp
(1.5 kW)
25 A @ 200–240 V, 1 Φ
15 A @ 200–240 V, 3 Φ
10 A @ 400–480 V, 3 Φ
10 A @ 575–600 V, 3 Φ
13.3 A
8.1 A
4.8 A
2.7 A
18 ft (5.5 m)
20 ft (6.1 m)
24 ft (7.3 m)
Powerfoil 8 Plus
Fan Diameter Motor Size Minimum Circuit Size Full Load Amps (Fan)
PP82-10 12 ft (3.6 m)
1.5 hp
(1.1 kW)
25 A @ 200–240 V, 1 Φ
15 A @ 200–240 V, 3 Φ
10 A @ 400–480 V, 3 Φ
10 A @ 575–600 V, 3 Φ
8.8–7.2 A
5.0–4.2 A
2.6–2.0 A
2.0–1.6 A
PP82-12 14 ft (4.3 m)
1.5 hp
(1.1 kW)
25 A @ 200–240 V, 1 Φ
15 A @ 200–240 V, 3 Φ
10 A @ 400–480 V, 3 Φ
10 A @ 575–600 V, 3 Φ
12.4–11.1 A
5.0–4.2 A
3.5–3.2 A
2.0–1.6 A
PP82-14 16 ft (4.9 m)
2.0 hp
(1.5 kW)
25 A @ 200–240 V, 1 Φ
15 A @ 200–240 V, 3 Φ
10 A @ 400–480 V, 3 Φ
10 A @ 575–600 V, 3 Φ
12.4–11.1 A
7.2–5.5 A
3.5–3.2 A
2.7–2.2 A
PP82-16 18 ft (5.5 m)
2.0 hp
(1.5 kW)
25 A @ 200–240 V, 1 Φ
15 A @ 200–240 V, 3 Φ
10 A @ 400–480 V, 3 Φ
10 A @ 575–600 V, 3 Φ
15.8–14.0 A
7.2–5.5 A
4.4–4.0 A
2.7–2.2 A
PP82-18 20 ft (6.1 m)
PP82-20 22 ft (6.7 m)
PP82-24 24 ft (7.3 m)
Powerfoil 8
Fan Diameter Motor Size Minimum Circuit Size Full Load Amps (Fan)
PF82-08 8 ft (2.4 m)
1.0 hp
(0.75 kW)
15 A @ 100–125 V, 1 Φ
15 A @ 200–240 V, 1 Φ
10 A @ 200–240 V, 3 Φ
10 A @ 400–480 V, 3 Φ
10 A @ 575–600 V, 3 Φ
9.0–7.2 A
8.7–7.6 A
5.0–3.8 A
2.4–2.1 A
1.3–1.0 A
PF82-10 10 ft (3.0 m)
PF82-12 12 ft (3.6 m)
1.5 hp
(1.1 kW)
25 A @ 200–240 V, 1 Φ
15 A @ 200–240 V, 3 Φ
10 A @ 400–480 V, 3 Φ
10 A @ 575–600 V, 3 Φ
12.4–11.1 A
5.0–4.3 A
3.5–3.2 A
2.0–1.6 A
PF82-14 14 ft (4.3 m)
PF82-16 16 ft (4.9 m)
2.0 hp
(1.5 kW)
25 A @ 200–240 V, 1 Φ
15 A @ 200–240 V, 3 Φ
10 A @ 400–480 V, 3 Φ
10 A @ 575–600 V, 3 Φ
15.8–14.0 A
8.1–4.8 A
4.4–4.0 A
2.7–2.2 A
PF82-18 18 ft (5.5 m)
PF82-20 20 ft (6.1 m)
PF82-24 24 ft (7.3 m)
