BIG ASS FANS Basic 6 - Fan Diagram

K
WWW.BIGASSSOLUTIONS.COM © 2016 DELTA T CORP. ALL RIGHTS RESERVED.
4
FAN DIAGRAM
Contact Customer Service if you are missing any parts or hardware needed for installation. Note: Powerfoil 8
illustrated below. Basic 6 has six airfoils and does not include the hub cover.
A
Safety Cable
E
Extension Tube
I
Winglet
B
Beam Clips & Spacers
F
Motor
J
Hub Cover
C
Upper Mount
G
Hub
K
Airfoil
D
Lower Yoke
H
AirFence™
A
B
C
D
E
G
H
I
Powerfoil Plus
Winglet
Powerfoil
Winglet
J
