Big Joe E30 - Page 77

BL-E30-0515 - 03-01-2018 12-7
Cap Assembly
Pos. # Part Number Description
Qty.
Reqd.
Notes
1 1120-342001-00 UPPER COVER 1
2 1120-342203-00 BUTTON FOR LIFTING(R) 1
3 1120-342202-00 BUTTON FOR LOWERING(R) 1
4 1120-342102-00 SPRING 8
5 1120-342201-00 BUTTON BRACKET(R) 1
6 1120-342105-00 PIN 6
7 1120-342104-00 BUTTON FOR LIFTING(L) 1
8 1120-342103-00 BUTTON FOR LOWERING(L) 1
9 1120-342101-00 BUTTON BRACKET (L) 1
10 1120-342002-00 HORN BUTTON 1
10a 1120-342005-00 PIN 2
10b 1120-342003-00 SPRING 2
10c 1120-342004-00 BUTTON BRACKET 1
11 0000-000039-00 SCREW ST3.5×9.5 6
12 0000-000490-00 HARNESS CLAMP 3
13 1120-342200-00 LIFT AND LOWER BOX(R) ASSY. 1
14 1120-342100-00 LIFT AND LOWER BOX(L) ASSY. 1
15 1220-520006-0C BUTTONS ASSEMBLY 1
16 1220-560002-00 MICRO SWITCH II 5
