THIRD MOVING MAST PARTS LIST
Item No. Part No. Description Qty
1 B16-01-0041 Third Moving Mast Weldment 1
2 0090-0770 Pin, Cotter, 3/16 x 1-1/2 in. 2
3 B36-01-0002 Axle, Sheave 3
4 0090-0425 Washer, Flat, 5/8 in. 6
5 B26-00-0009 Sheave Assembly, Chain 2
6 0090-0389 Screw, Set, 1/2-20 x 1/2 in. 8
7 0090-0403 Screw, Sheet Metal, #10 x 1 in. 4
8 B31-00-0001 Slide Block, Plastic 4
9 B40-00-0003 Cable, Steel, 3/16 in. 1
10 B40-01-0008 Chain, Lift 2
11 B04-07-0078 Pin, Clevis 2
12 B04-07-0087 Clevis, Lower 2
13 0090-0042 Screw, Cap, 3/8-16 x 1 in. 6
14 B29-00-0033 Mast Stop 1
15 0090-0210 Washer, Lock, Split, 3/8 in. 6
16 0090-0162 Nut, Hex, 3/8-16 6
17 0090-0860 Pin, Cotter 2
18 B29-00-0078 Bracket, Weldment 1
19 0090-0147 Pin, Cotter, 1/8 x 1-1/4 in. 1
20 B24-01-0008 Mounting Bracket 1
21 B26-00-0001 Sheave, Cable 1
* B03-00-0009
Chain Assy, includes items 10, 11, 12, 17
and Upper Clevis & Lock Nut (shown on
1
