HYDRAULIC PUMP COMPARTMENT ASSEMBLY
Item No. Part No. Description Qty
1 B01-10-0291 Converter, 24 Volt DC-DC 1
2 0090-0183 Nut, Nylon Lock, 1/4-20 22
3 0090-0419 Washer, Flat, 1/4 in. 6
4 0090-0005 Screw, Cap, 1/4-20 x 3/4 in. 16
5 0090-0210 Washer, Lock, Split, 3/8 in. 5
6 0090-0162 Nut, Hex, 3/8-16 1
7 B04-07-0036 Clamp, Cable/Hose, DG 16 4
8 0090-0232 Screw, Machine, #10-24 x 5/8 in. 1
9 0090-0001 Screw, Cap, 1/4-20 x 1/2 in. 2
10 0090-0415 Washer, Flat, #10 1
11 B01-06-0053 Relay, 24 Volt DC, 20 Amp 1
12 0090-0182 Nut, Nylon Lock, #10-24 1
13 B02-15-0425 Solenoid, Start, 24VDC 1
14 B01-05-0056
Charger, Battery, 40 Amp, 110 Volt AC, 60
1
15 B04-07-0015 Clamp, Tie Wrap 3
16 B01-10-0280 Control Board, Main 1
17 B01-10-0194 Alarm, Audible 1
18 0090-0422 Washer, Flat, 3/8 in. 4
19 0090-0040 Screw, Cap, 3/8-16 x 3/4 in. 2
20 B01-10-0247 Sensor, Level, 1.0 Degree 1
21 B29-00-0021 Bracket, Level Sensor Mount 1
22 B11-01-0147 Rear Guard 1
23 B30-00-0061 Bumper, Corner 2
24 0090-0344 Screw, Threadcutting, #10-24 x 1/2 in. 8
25 0090-0048 Screw, Cap, 3/8-16 x 2 in. 2
26 B02-05-0034
Pump, Hydraulic (see pages 6-26 & 6-27
for component parts listing)
1
SEE APPENDIX B FOR MACHINE CHANGES DUE TO
REFURBISHMENT
