Bil-Jax ESP 19 - Upper Control Box Parts List

75
UPPER CONTROL BOX PARTS LIST
Item No. Part No. Description Qty
B01-10-0273 Joystick Assembly 1
1 B01-10-0198 Circuit Board, Joystick (Not Shown) 1
2 B01-10-0201 Stop Switch, Emergency 1
3 B01-10-0205 Protection Skin, Push Button 3
4 B01-10-0202 Push Button, Arrow Up 1
5 B01-10-0203 Push Button, Arrow Down 1
6 B01-10-0204 Push Button, Enable 1
7 B01-10-0207 Mini Lamp, 6.3 volt 3
8 B01-10-0206 Switch, Cherry, Water/Dust Proof 3
9 B01-10-0317 Plate, Top Control 1
10 B01-10-0264 Joystick 1
11 B01-10-0318 Plate, Drive Direction 1
12 B01-10-0311 Rubber Cup, Thumb Switch 1
13
B01-10-0312-
Handle, Joystick, Left Half 1
14 B01-10-0313 Rubber Cord 2
15
B01-10-0312-
Handle, Joystick, Right Half 1
16 B01-10-0315 Switch, Thumb Actuator 1
17 B01-10-0314 Lever, Enable Switch 1
18 B01-10-0305 Pin, Dowel, 1/8 x 3/4 in. 1
19 B01-10-0316 Pushbutton, Enable Switch
20 0090-0500 Screw, Machine, #4-40 x 3/4 in. 2
21 B01-10-0218 Clamp 1
22 B01-10-0217 Screw, Machine, Torx, #6-32 x 3/8 in. 2
23 B01-10-0210 Boot, Rubber 1
24 0090-0243 Screw, Machine, #10-32 x 1/2 in. 2
25 B01-10-0209 Washer, Plastic 2
26 B01-10-0208 Gasket, Foam 1
27 B01-10-0306 Pin, Dowel, 3/16 x 3/4 in. 1
28 B01-10-0308 Spring, Torsion 1
29 B01-10-0307 Gear, 24 Tooth, Switch Activation 1
30 B01-10-0310 Bushing, Flanged 1
31 B01-10-0309 Standoff, Hex 2
32 0090-1087
Screw, Machine, Panhead, #6-32 x
2
