BASE ASSEMBLY PARTS LIST
Item No. Part No. Description Qty
1 B07-01-2003 Edge, Top Cover 1
2 0090-0344 Screw, Threadcutting, #10-24 x 1/2 in. 8
3 B05-00-0005 Tape, Foam Adhesive 32 in.
4 B18-00-0177 Plexiglass, 1/8 in. 1
5 B24-01-0013 Frame, Aluminum, 18-1/4 in. 2
6 B24-01-0009 Frame, Aluminum, 20 in. 1
7 B37-00-0006 Lock Assembly, Utility 2
8 B01-10-0194 Alarm, Audible 1
9 0090-0182 Nut, Nylon Lock, #10-24 2
10 B01-09-0003 Strain Relief, Cable 1
11 B01-02-0076 Control Box Assembly, Lower 1
12 B19-00-0040 Box, Switch, 3 Position 1
13 B01-02-0078 Contacts, Switch, Normally Open 4
14 B01-02-0079 Contacts, Switch, Normally Closed 2
15 B01-02-0082 Switch, Selector, Keyed 1
16 B01-02-0081
Switch, Pushbutton, Emergency
1
17 B01-02-0080 Switch, Selector, Up/Down 1
18 B00-00-0131 Legend Plate, Upper/Off/Lower 1
19 B00-00-0130 Legend Plate, Emergency Stop 1
20 B00-00-0129 Legend Plate, Up/Down 1
21 B38-00-0001 Key, Replacement 1
22 0090-0232 Screw, Machine, #10-24 x 5/8 in. 2
23 B11-01-0146 Weldment, Base and Mast 1
24 B01-02-0060 Switch, Master Power 1
25 B00-00-0112 Faceplate, Master Power Switch 1
26 B01-10-0294 Battery Gauge/Hour Meter 1
27 B01-03-0065 Switch, Battery Charger Cord Box 1
28 B19-00-0045 Box, Battery Charger Cord 1
29 B01-01-0143 Cord, Retractable, 16-3 1
30 B04-07-0032 Clamp, Cord, DG-6 1
31 0090-0005 Screw, Cap, 1/4-20 x 3/4 in. 3
32 0090-0183 Nut, Nylon Lock, 1/4-20 3
SEE APPENDIX B FOR MACHINE CHANGES DUE TO
REFURBISHMENT
