CYLINDER, FITTINGS AND HOSES PARTS LIST
Item No. Part No. Description Qty
1 B02-03-0040
Cylinder, Hydraulic Lift, 1.75 in. Bore x 54
in. Stroke
1
2 Wiper, Rod 1
3 B02-13-0096 Nut, Gland 1
4 Packing 1
5 O-Ring 1
6 NSS Piston Rod 1
7 Ring, Wear 1
8 NSS Jacket, Cylinder 1
9 B02-02-0230
Fitting, 4MFS-4ORM 90°
2
10 B02-03-0038
Cylinder, Hydraulic Steering, 1.5 in. Bore x
4 in. Stroke
1
12 B02-04-0094 Valve, Flow Control, 1.25 gpm 1
11 B02-02-0237 Fitting, Straight, 4ORFS-6ORB 1
13 B02-01-0186
Hose, Hydraulic, #4 x 22 in.
w/2 - #4FMFS fittings
3
14 B02-02-0229
Fitting, 4MFS-6ORM 90°
3
15 B02-05-0034 Pump, Hydraulic 1
16 B02-15-0445 Valve 1
17 B01-08-0018 Coil 1
Handle and knob assembly
* B02-13-0097 Seal Kit (Includes items 2, 4, 5, and 7
