59
FOURTH MOVING MAST PARTS LIST
Item No. Part No. Description Qty
1 B16-01-0042 Fourth Moving (Platform) Mast Weldment 1
2 0090-0014 Screw, Cap, 1/4-20 x 2-1/4 in. 2
3 B01-09-0026 Grommet, Plastic 2
4 B29-00-0160 Bracket, Outreach 1
5 0090-0206 Washer, Lock, Split, 1/4 in. 2
6 0090-0159 Nut, Hex, 1/4-20 2
7 B31-00-0001 Slide Block, Plastic 2
8 0090-0389 Screw, Set, 1/2-20 x 1/2 in. 4
9 0090-0403 Screw, Sheet Metal, #10 x 1 in. 2
10 B01-10-0275 Light, Caution 1
11 0090-0802 Screw, Machine, #10-24 x 7/8 in. 2
12 0090-0182 Nut, Nylon Lock, #10-24 2
13 B04-07-0087 Clevis, Lower 2
14 B04-07-0078 Pin, Clevis 2
15 0090-0860 Pin, Cotter 2
16 B40-01-0008 Chain, Lift 2
17 B40-00-0003 Cable, Steel, 3/16 in. 1
18 B07-01-2033 Edge, Top Cover 1
19 0090-0344 Screw, Threadcutting, #10-24 x 1/2 in. 4
20 B18-00-0178 Plexiglass, 1/8 in. 1
21 B24-00-0011 Frame, Aluminum, 11-1/2 in 1
* B03-00-0009
Chain Assy, includes items 13, 14, 15, 16
and Upper Clevis & Lock Nut (shown on
1
