HYDRAULIC UNIT PARTS LIST
Item No. Part No. Description Qty
B02-05-0034 Pump Unit Complete 1
1 B02-15-0423 Reservoir, Plastic 1
2 B02-15-0412 Clamp, Reservoir 1
3 B02-15-0418 Breather Cap 1
4 B02-15-0438 Valve Assembly, 24VDC 1
5 0090-1060
Screw, Socket Head Cap, 1/4-20 x 2-3/4
7
6 B02-15-0444 Cap, Cartridge Valve 2
7 B02-15-0440 Valve, Pilot Operated Check 1
Spring for Pilot Operated Check Valve 1
8 B02-15-0441 Valve, Flow Control 2
9 B02-15-0442 Valve, Cartridge, 3 Way-2 Position 3
10 B02-15-0439 Valve Manifold 1
11 B02-15-0443 Valve, Cartridge Relief 1
12 B02-15-0425 Solenoid, Start, 24VDC 1
13 B02-15-0490 Plug, Nylon, Motor 2
14 B02-15-0424 Motor, Electric, 12VDC 1
15 B02-15-0491 Bearing, Motor 1
16 B02-15-0420 Base Assembly, Pump 1
17 B02-15-0433 Screw, Spring Retainer, 9/16-18 1
18 B02-15-0432 Spring, Check Valve 1
19 B02-15-0431 Poppet, Ball Retainer 1
20 B02-15-0430 Ball, 5/16 in. Diameter 1
21 B02-15-0426 Base, End Head 1
22 B02-15-0429 Seal, Shaft 1
23 B02-15-0427 Bearing, Needle 2
24 B02-15-0434 Spring, Retaining, Port Filter 1
25 B02-15-0435 Filter, Screen 1
26 B02-15-0436 Valve, Cartridge Relief 1
27 B02-15-0437 Seal, O-Ring, 3-7/8 x 1/8 in. 1
28 B02-15-0428 Seal, O-Ring, 5/8 x 1/16 in. 1
29 B02-15-0401
Tube, Return, 1/8 NPT, 90°
1
30 B02-15-0421 Pump Assembly 1
31 B02-15-0403
Tube, Return, 3/8 NPT, 90°
1
32 B02-15-0404 Filter, Screen (Suction) 1
