BATTERY COMPARTMENT PARTS LIST
Item No. Part No. Description Qty
1 0090-0183 Nut, Nylon Lock, 1/4-20 7
2 B04-07-0036 Clamp, Cable/Hose, DG 16 1
3 B01-01-0144 Cable, Battery, 2 Ga. x 104 in. 1
4 B01-01-0027 Cable, Battery, 2 Ga. x 19 in. 1
5 B01-01-0130 Cable, Battery, 4 Ga. x 68 in. 1
6 0090-0188 Nut, Nylon Lock, 3/8-16 1
7 B01-10-0343 Controller, Motor 1
8 0090-0028 Screw, Cap, 5/16-18 x 3/4 in. 2
9 0090-0208 Washer, Lock, 5/16 in. 2
10 B01-01-0131 Cable, Battery, 8 Ga. x 16 in 1
11 B01-01-0014 Cable, Battery, 2 Ga. x 8 in. 1
12 B01-04-0015 Battery, Maintenance-Free, 12 Volt 2
13 B07-01-1144 Bracket, Battery Clamp 2
14 0090-0419 Washer, Flat, 1/4 in. 8
15 0090-0005 Screw, Cap, 1/4-20 x 3/4 in. 6
16 B18-00-0179 Underguard 1
17 B01-06-0053 Relay, 24 Volt DC, 20 Amp 1
18 B01-10-0135 Sensor, Level, 1.5 Degree 1
19 B01-01-0113 Plug, Level Sensor 1
20 B01-03-0061 Switch, Limit, Underguard 2
21 B01-01-0122 Cable Assembly, Underguard Switch 2
22 B07-06-5953 Clamp, Underguard 4
23 0090-0001 Screw, Cap, 1/4-20 x 1/2 in. 8
24 B39-00-0049 Spring 4
25 0090-0415 Washer, Flat, #10 8
26 0090-0182 Nut, Nylon Lock, #10-24 4
27 B04-07-0015 Clamp, Cable 1
28 0090-0232 Screw, Machine, #10-24 x 5/8 in. 4
SEE APPENDIX B FOR MACHINE CHANGES DUE TO
REFURBISHMENT
29 B11-01-0148 Front Guard 1
30 0090-0048 Screw, Cap, 3/8-16 x 2 in. 2
31 0090-0210 Washer, Lock, Split, 3/8 in. 2
32 0090-0422 Washer, Flat, 3/8 in. 2
