85
EUCLID MOTOR FLANGE MOUNT PARTS LIST
Item No. Part No. Description Qty
1 B11-01-0162 Euclid Motor Mount 1
2 B25-00-0073 Pillow Block 2
3 B07-06-5946 Pillow Block Spacer 2
4 0090-0506 Cap Screw, 1/2-13 x 2 1/2 4
5 0090-0068 Cap Screw, 1/2-13 x 1 3/4 8
6 0090-0192 Hex Nut, 1/2-13 8
7 B08-02-0029 Wheel, 10” 2
8 B07-07-5022 Bar, Square, 1/4 x 2 1/4 2
9 0090-0776 Washer, Flat, 1/2 2
10 0090-1138 Cap Screw, 7/16-13 x 1 1/2 2
