Battery information as below:
Electrical power
Voltage Rating
400mAh ,2 X 1.2V AAA Size
Voltage Rating
400mAh, 2 X 1.2V AAA Size
TECHNICAL DETAILS
Standard
Frequency range
Channel bandwidth
Operating range
Operating time
Temperature range
Digital Enhanced Cordless
Telecommunication (DECT)
1.88 to 1.9 GHz
1.728 MHz
Up to 300m outdoors;
Standby: 1 hours,
Talking: 10 hours
Battery charge time:15 hours
Operating 0 C to 40 C,
Storage -20 C to 60 C
(bandwidth = 20 MHz)
Up to 50m indoors
Caution
Risk of explosion if battery is replaced by an incorrect type
Dispose of used batteries according to the instructions.
The port (connected to the mains power supply) is a SELV port with
The port (connected to the telephoneline ) is a TNV port with
respect to EN41003.
CLEANING AND CARE
Do not clean any part of your phone system with benzene, thinners or other
solvent chemicals as this may cause permanent damage which is not covered
by the Guarantee.
When necessary, clean it with a damp cloth.
Keep your hot, humid conditions
or
strong sunlight, and don't let it get wet.
Every effort has been made to ensure high standards of reliability for your
consult your supplier or the Helpline.
do
not try to repair it yourself
phone system away from
Port specification
respect to EN41003.
phone system. However If something does go wrong, please
Baseunit:
TenPao:S003IB0600050&S003IV0600050
Input100-240Vac50-60Hz,output6Vdc/500mA.
Chargerunit:
TenPao:S003IV0600015&S003IB0600015
Input100-240Vac50-60Hz,output6Vdc/150mA.
SANIK – SN-AAA40H, Type NiMH (Rechargeable battery)
HFEHFR-AAA400,
T
ype NiMH (Rechargeable battery)
68
