VD (E2.1) 10/2011 page 11/83
1.4 Type plate
Figure 2: Position of type plate
Figure 3: Type plate (example of VD 23 regular unit)
Indications of the type plate Information
BINDER Manufacturer: BINDER GmbH
VD 23 Model VD 23
Serial No. 00-00000 Serial No. 00-00000
Nominal temperature 200 °C
392 °F
Nominal temperature
Enclosure protection IP 20 IP type of protection 20 acc. to EN 60529
Temp. safety device DIN 12880 Temperature safety device acc. to standard DIN 12880
Class 2.0 Temperature safety device, class 2
Art. No. 9030-0029 Art. No. 9030-0029
Project No. --- (Special application acc. to project no.)
0,80 kW Nominal power 0,80 kW
230 V 1 N ~
Nominal voltage 230 V ± 10%, single-phase unit
3,5 A Nominal current 3,5 Amp
50/60 Hz Power frequency 50/60 Hz
Nominal temperature 200 °C 0,80 kW
392°F 230 V 1 N ~
Enclosure protection
Temp. safety device
IP 20
DIN 12880
3,5 A
50/60 Hz
Class 2.0
Art. No. 9030-0029 US PATS 4585923 / 5222612 / 5309981
Project No. 5405194 / 5601143 / 5773287 / 6079403
D 78532 Tuttlingen / Germany
Tel. + 49 (0) 7462/ 2005-0
Internet: www.binder-world.com
VD 23 Serial No. 00-00000
Made in Germany
