Binder APT.line VD - Equipment and Options

VD (E2.1) 10/2011 page 75/83
Unit size 23 53 115
Electrical data
IP protection type according to EN 60529 IP 20 IP 20 IP 20
Nominal voltage (±10%) 50/60 Hz V 230 230 230
Nominal power kW 0.80 1.20 1.90
Unit fuse 5 x 20 mm / 250V /
middle-time-lag (M)
Amp 10 10 10
Power plug shock proof plug
Power plug vacuum module (option) shock proof plug
at 100 °C / 212°F Wh/h 105 150 250 Energy consumption
at 200 °C / 392°F Wh/h 280 445 785
Over-voltage category acc. to IEC 61010-1 II II II
Pollution degree acc. to IEC 61010-1 2 2 2
Electrical connection data cUL-version (for the USA and Canada)
Unit size 23 53 115
Electrical data
Nominal voltage (±10%) 60 Hz / 1N V 115 115 115
Nominal power kW 0.80 1.20 1.70
Nominal current A 7.0 10.5 14.8
Unit fuse 6.3 X 32 mm / 250V / super-time-lag
TT
A 12.5 12.5 20
Power plug NEMA 5-15P 5-15P 5-20P
Power plug vacuum module (option) NEMA 5-15P 5-15P 5-20P
Over-voltage category acc. to IEC 61010-1 II II II
Pollution degree acc. to IEC 61010-1 2 2 2
Legend:
1) Values only in combination with aluminum racks
2) Time to reach 98% of the set point temperature
All technical data is specified for units with standard equipment at an ambient temperature of +25 °C /
77°F and a power supply voltage fluctuation of ±10. The temperature data is determined in accordance to
BINDER factory standard following DIN 12880, observing the recommended wall clearances of 10% of
the height, width and depth of the inner chamber.
All indications are average values, typical for units produced in series. We reserve the right to
change technical specifications at any time.
20.3 Equipment and Options
To operate the vacuum drying oven VD, use only original BINDER accessories or accessories
/ components from third-party suppliers authorized by BINDER. The user is responsible for
any risk arising from using unauthorized accessories.
Regular equipment
Microprocessor program controller RD3 with LED display
Safety device cl.2 according to DIN 12880
RS 422 printer and communication interface with adjustable printing intervals
Fine-dosing aeration valve
