VD (E2.1) 10/2011 page 31/83
Display 1 shows e.g. 2006 (Actual setting: 2006)
Display 2 shows Year 2006 (Setting the year of the real time clock)
Set year (2006 up to 2050) using arrow keys
Setting is shown in display 2.
Press key
Display 1 shows e.g. 5 (Actual setting: may)
Display 2 shows Month 5 (Setting the month of the real time clock)
Set month (1 up to 12) using arrow keys
Setting is shown in display 2.
Press key
Display 1 shows e.g. 15 (Actual setting: 15)
Display 2 shows Day 15 (Setting the day of the real time clock)
Set day (1 up to 31) using arrow keys
Setting is shown in display 2.
Press key
EXIT
Press key
Display 1 shows 0000
Display 2 shows Time (Main menu: Setting the time of the real time clock)
Press program key
Display 1 shows e.g. 13 (Actual setting: 13, i.e. 1 p.m.)
Display 2 shows Hour 13 (Setting the hour of the real time clock)
Set hour (0 up to 23) using arrow keys
Setting is shown in display 2.
Press key
Display 1 shows e.g. 30 (Actual setting: 30 minutes)
Display 2 shows Minute 30 (Setting the minute of the real time clock)
Set minute(0 up to 59) using arrow keys
Setting is shown in display 2.
Press several times key
EXIT
or wait for 120 seconds
Controller returns to normal display.
2. Enter the set-points for the week program in Fixed value entry mode (see chap.
6)
Set-points for the example program:
SP1 (night / weekend) = 30 °C (Channel 1 ON = Controller adjusts to set-point SP2)
SP2 (day / week) = 80 °C (Channel 1 OFF = Controller adjusts to set-point SP1)
Normal Display
Display 1 shows e.g. 39.8
C
(actual temperature value)
Display 2 shows
e.g. 15.05.06 13:52 - -
(actual date and time, actual switching state of week
program timer channel 1: Off, channel 2: Off)
Press key
Display 1 shows 30.0
C
(actual temperature set-point 1)
Display 2 shows SP1 TEMPERATURE (variable: temperature in °C)
Enter temperature set-point 30 °C using
arrow keys
Value is shown in display 1.
