Chapter 6. Specification
ECG Leads
Simultaneous 12 Leads Resting ECG
Recording Channel
3CH+1RHY, 3CH+3RHY, 6CH+1RHY, 12CH, 6CH+ST map
1CH Long Time (1min, 3min, 5min,10min) and
Special Beat Report (Text, Guide, Vector, ST map)
Gain
2.5, 5, 10, 20, Auto (I~aVF: 10, V1~V6: 5) mm/mV
Printing Speed
5, 12.5, 25, 50, 100 mm/sec
Sampling Rate
Analysis Sampling Rate - 500
Digital Sampling Rate - 8,000
Filters
AC (50/60 Hz, -20dB or better),
Muscle (25~35Hz, -3dB or better),
Baseline drift (0.05Hz, 0.1Hz, 0.2Hz, -3dB or better),
Low pass filter (off, 40Hz, 100Hz, 150Hz)
Display
800 x 480-pixel resolution, 7” Color TFT wide display
12 channels preview, ID, HR, Gain, Speed, Power status
User Interface
Touch screen, Rotary push-knob
Printer Resolution
Thermal print head, Roll Paper
Report paper
- width: A4/Letter 215mm (8.5”)
- length: A4 297 mm (11.7”)
Letter 279mm (11”)
Resolution: 8dot/mm (0.125mm pitch)
Patient data
ID, name, age, gender, height, weight, race, smoke,
department, room number, study desc., accession no.,
referring physician
Basic Measurement
Heart rate (30~300bpm, ±3bpm), PR/RR int., QRS dur., QT/QTc int.,
P-R-T axis, SV1/RV5/R+S amp.
ECG Data Storage
Internal Storage for 200 ECGs: Built- in memory
Electrical
Internal noise: 20uV(p-p) max
Input impedance: ≥ 50MΩ
Input voltage range: ±5mV
CMRR: > 105dB
DC offset voltage: ≥ ±400mV
Patient leakage current: < 10uA
Frequency response: 0.05 ~ 200 with in –3dB
Isolated, defibrillation and ESU protected
Signal Quality
Control
Pacemaker pulse detection
Lead fault detection, Signal Saturation Detection
Line Power
Input: 100-240Vac, 1.5-0.75A, 50-60Hz,
Output: 15Vdc, 4.2A
