- Check the status of equipment and attachment to patient’s body before measuring.
- Check for any mechanical danger.
- Check cables and accessories connected to the outside.
- Check all the devices to measure the patient.
Patient Cable Connection
Connect the device cable to the patient cable connection port on the right side of the
main body, and then connect electrodes for extremities to the terminal of patient cable RL
(N), LL (F), RA(R) and LA (L), while you can connect electrodes for the chest to the terminal
of ‘V1 (C1), V2 (C2), V3 (C3), V4 (C4), V5 (C5) and V6 (C6).
How to Attach Electrodes
Lay down the patient on the bed and let the patient relax. Attach the electrodes
cleaned with water or antiseptic alcohol to the patient’s body. If it is hard to attach
the electrodes due to the patient’s hairs or curves of the body, apply the ECG gel.
Please make sure the electrodes are attached correctly as explained above. When
using the gel, please remove the gel after use as it may cause noise of the ECG
signals.
Use only electrodes and patient cables provided from Bionet, Inc. Bionet
America, Inc. will take no responsibility for any accidents involving 3
rd
party
accessories.
