5) LCD Monitor display
Monitor mode display shows the currently measured electrocardiogram signal in real time.
The monitor mode display function is used for the following two purposes: One is to check
whether the signals from all channels are coming out properly; the other one is to see the
status of the electrocardiogram of the patient for an extended time.
The printing speed can be selected to 5mm/s, 12.5 mm/s, 25 mm/s, 50mm/s and 100 mm/s,
and the sensitivity can be selected to 2.5 mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV, and
Auto.
Displayed heart rate is the average of 4 heartbeats
NOTE
The heart rate is between 30 ~ 300 bpm, and the error range is ±3.
