Printing speed Setup
This is a function to adjust the width of the printing signal. The values are available
in 12.5mm/sec, 25mm/sec and 50mm/sec. If you set 25mm/sec up, the ECG signal
will be recorded in 25mm for one second.Therefore, the 12.5 mm/sec width is equal to
half of the 25 mm/sec width; the 5 mm/sec with is equal to 1/5 of the 25 mm/sec width.
The 50mm/sec width is equal to twice that of the 25mm/sec width; the 100mm/sec width
is equal to twice that of the 50mm/sec width.Therefore, if you want to have a wide
signal, set up the bigger value.
Note
- When monitoring is set to ‘Mon Size’ -> ‘A4’, the printing speed is 25mm/s.
- if Recording is set as Long time 3 min, 5 min and 10 min, the resulting output will
be in 12.5 mm/sec.
