When clicking the ‘Format’ button, a line window will show up and it will disappear
when selecting EKG/FVC/SVC/MVV, MFER(ECG), XML(ECG), JPEG, PDF. ‘Format’ menu is
used to select the user’s options when transferring the data.
- EKG/FVC/SVC/MVV: To save the data by type of ‘***.
ekg'/ ‘***.fvc'/ ‘***.svc'/ ‘***.mvv'
- MFER: To save the data by type of ‘***.mwf'
- XML: To save the data by type of ‘***.xml'
- JPEG: To save the data by type of ‘***.jpg'
- PDF: To save the data by type of ‘***.pdf'
- DICOM: To save the data by type of ‘***.dcm’
When clicking the ‘Delete’ button, a line window will show up and it will disappear
when selecting Yes or No. ‘Delete’ menu is used to select the user’s options after the
data has transferred.
- Yes: To delete the data after it has transferred
- No: To not delete the data after it has transferred
NOTE
- If ‘Format’ menu has only ‘EKG/FVC/SVC/MVV’ options, it is possible to select 'All' or
'All New' in 'Method’ menu; for other formats, ‘Selected’ is the only option.
5) Switching menu
When selecting the ‘Main’ button at the main page of ‘File management’, a line window
will show up. You can choose ECG, Spiro or Worklist to go to the chosen page.
The patient’s information of selected data does not transmit when skipping to ‘Worklist
Management’ screen. But it depends on the setting value of ‘PAT Info.’ menu when
skipping to ‘ECG’ main screen.
- ECG: Skip to ECG main screen
- Worklist: Skip to ‘Worklist Management’ screen
- Spiro: Skip to spirometry measurement screen
