- Menu Navigation
Operate by rotating the rotary key. Menu movement will occur in the same direction
as the direction of the key’s rotation.
- Menu Selection
Initiate by pressing the rotary key. Menu box for setting of the selected menu will be
displayed.
- Modifying setting values
Move to desired setting, then modify & select values in the same manner as menu
movement shown above. When you select either 5mm/sec, 12.5mm/sec,
25mm/sec, 50mm/sec or 50mm/sec at the ‘Speed Setting’ POP-UP, the POP-UP
window will disappear.
Using the touch screen to modify the information
When using the touch screen, only two procedures, menu selecting and
information modification, are required.
- Select Menu
Press the menu on the screen. Unlike the rotary key, the menu box you want
to set up will show at the same time.
- Change the value
Press the chosen item on the screen after moving to the page.
