bioscrypt V-Flex 4G - V-Flex 4 G Flush-Mount Mounting Plate; V-Flex 4 G Recessed-Mount Mounting Plate

October152009–InstallationGuideDraft–EditPurposesOnly Page45
Installation Guide – October 2009 – Edit Purposes Only
2009
gang box and use wall anchors on the remaining four holes for additional security.
To install the mounting plate on to an electrical box, screw the mounting plate to the box
with the provided 6-32 screws.
CAUTION
When installing a recess-mounted V-Flex 4G device, be careful not
to damage the tamper switch, as careless handling can shear it off.
Figure 4-1 V-Flex 4G Flush-mount Mounting Plate
Figure 4-2 V-Flex 4G Recessed-mount Mounting Plate
