October152009–InstallationGuideDraft–EditPurposesOnly Page46

Installation Guide – October 2009 – Edit Purposes Only

2009

Figure 4-3 V-Station 4G Mounting Plate

NOTICE

The V-Station 4G device can only be flush mounted.
