Setting Up the 405 TS| 15
Waste System
Caution! Pump Installation. Do not plug the vacuum pump cable into a wall
outlet! Use the adapter provided with the pump to connect it to the Accessory
Outlet on the back of the instrument. This allows the 405 TS to regulate the
pump, turning it on and off as specified by the protocol.
When using a standard pump (rather than the high flow pump), set the
instrument’s Vacuum Dissipation Delay to prevent the pump from drawing
excess current and blowing the 5-amp fuse. See Define Instrument Settings on
page 22
l Note: The waste tubes have colored bands that match similarly colored
dots next to the inlet/outlet ports on the waste bottle caps to ensure the
correct connection of the tubing.
Waste System
BioTek Instruments, Inc.
