Operating instructions iS10 / iS20 Operation
38019417000 en 27
5
5.6 Change the tens digit for input of numbers
In order to change from a 1-digital to a 10-digital decade in case of two-digital menu num-
bers, proceed as follows:
Key Display presentation Process description
Example: PC/EDP interface parameter is called
up.
The first parameter is displayed.
The tens digit is selected.
A bar above the tens digit marks the selection.
or
Select desired parameter number.
or
The ones digit is selected.
A bar above the ones digit marks the selection.
or
Select desired parameter number.
Confirm input with .
5.7 Display metrological data
The verification status displays if there were verification relevant parameter changes. Fur-
thermore, the identification of the connected load cell will be displayed.
Key Display presentation Process description
Weight symbol flashing: Calibration switch is not
secured.
Weight symbol static: Calibration switch is in se-
cured status.
