Operating instructions iS10 / iS20 Operation
38019417000 en 45
5
5.12.12 Display tendency control
Key <F1> is assigned with "toLE_CH", see page 25.
Key Display presentation Process description
Display of tendency control.
Return to weighing mode.
5.13 Recording operation
For the formation of totals, weighed items are recorded in a memory with net weight, tare
weight and gross weight and number of pieces. Weight values without tare functions are
simultaneously totaled to form gross and net weight.
The recording process with acquisition of the weight value, PC/EDP dialog and printout, is
marked in the display by the
recording icon. For each dimension kg and lb there are
separate total memories available.
*Total memory
– Net weight, number of pieces, item counter
– consecutive number with counting of each item recording
The consecutive number is reset at 999999!
Differences between *gross weight and *net weight + *tare weight can
appear due to:
– Net weighing with tare balance, taring (fine division) with weighed
tare value.
– Subtractive weighing
If equipped with a serial interface and relevant parameter setting the data is sent to a con-
nected PC/EDP or output from the connected printer.
5.13.1 Item recording, adding
Key Display presentation Process description
Registration process
The weight value is added to the memory *kg.
Consecutive number and item counter are in-
creased.
