Bizerba VS12F - Name of Components VS12 F-P

Operating instructions VS12 /C /F /F-P /W About this machine
6.080.98.5.10.13 en 2 - 7
2
13
Product rail
14
Gauge plate
15
Deflector
16
Three-square knob for blade cover
17
Membrane keyboard On/Off with signal lamp
2.2.4 Name of components VS12F-P
Fig. 4: Name of components VS12F-P
The machine is available in different versions. The figure shows an example:
1
Blade guard ring
2
Blade
3
Blade cover
4
Product holder
5
Handle for product holder
6
Carriage
