Maintenance Operating instructions VS12 /C /F /F-P /W
8 - 2 6.080.98.5.10.13 en
8
8.2 Removing components
WARNING For fast and easy installation, the remnant holder is fixed to the
guiding shaft by means of a magnet lock.
If the distance to the magnet is lower than 50 mm, pacemakers can
be affected.
–
People with pacemakers should consult a doctor before operating
the machine.
Do not place parts on top of each other to avoid mechanical damage.
Remove components as follows:
Remnant holder plate VS12,VS12F,VS12W
Fig. 35: Remnant holder plate
Using the handle, move product holder
away from blade and tilt it up.
Push remnant holder plate out of mag-
netic lock and remove from pusher
guard.
For quick and easy handling, the remnant
holder is attached to the pusher guard by
a magnet lock.
If the distance is less than
50 mm, pacemakers can be affected.
