Operating instructions VS12 /C /F /F-P /W Technical data
6.080.98.5.10.13 en 9 - 1
9
9 Technical data
9.1 Dimensions VS12
Fig. 63: VS12, example
The machine is available in different versions. The figure shows an example:
Outer dimensions:
1
Length
= 625 mm = 24.6"
2
Width
= 570 mm = 22.4"
3
Height
= 488 mm = 19.2"
Installation surface:
4
Length
= 520 mm = 20.5"
5
Width
= 430 mm = 17"
Work area:
6
Length
= 672 mm = 26.5"
7
Width
= 740 mm = 29.1"
Weight
= approx. 42 kg = 93 lb
Blade diameter = 330 mm = 13"
Blade speed = 266 rpm
max. product size, diam-
eter
= 224 mm = 8.8"
Max. product height = 260 x 224 mm = 10.2" x 8.8"
