Bizerba VS12F - Dimensions VS12 F

Technical data Operating instructions VS12 /C /F /F-P /W
9 - 2 6.080.98.5.10.13 en
9
Slice thickness setting = 0.5 to 24 mm = 0.02" to 0.95", stepless
Types of current, voltag-
es, power consumptions
= see rating plate
9.2 Dimensions VS12F
Fig. 64: VS12F, example
The machine is available in different versions. The figure shows an example:
Outer dimensions:
1
Length
= 706 mm = 27.8"
2
Width
= 674 mm = 26.5"
3
Height
= 536 mm = 21.1"
Installation surface:
4
Length
= 605 mm = 23.8"
5
Width
= 430 mm = 16.9"
Work area:
6
Length
= 860 mm = 33.9"
7
Width
= 770 mm = 30.3"
Weight = approx. 50 kg = 110 lb
Blade diameter = 350 mm = 13.8"
Blade speed = 266 rpm
max. product size, diam-
eter
= 270 mm = 10.6"
Max. product height = 315 x 260 mm = 12.4" x 10.2"
