Technical data Operating instructions VS12 /C /F /F-P /W
9 - 6 6.080.98.5.10.13 en
9
Work area:
6
Length
= 890 mm = 35"
7
Width
= 730 mm = 28.4"
Weight
= approx. 54 kg = 119 lb
Blade diameter = 370 mm = 14.6"
Blade speed = 266 rpm
max. product size, diam-
eter
= 270 mm = 10.6"
Max. product height = 325 x 260 mm = 12.8" x 10.2"
Slice thickness setting = 0.5 to 24 mm = 0.02" to 0.95", stepless
Types of current, voltag-
es, power consumptions
= see rating plate
9.6 Dimensions VS12W
Fig. 68: VS12W, example
The machine is available in different versions. The figure shows an example:
Outer dimensions:
1
Length
= 625 mm = 24.6"
2
Width
= 570 mm = 22.4"
3
Height
= 488 mm = 19.2"
Installation surface:
4
Length
= 520 mm = 20.5"
5
Width
= 430 mm = 17"
