Bizerba VS12F - Dimensions VS12 F37

Operating instructions VS12 /C /F /F-P /W Technical data
6.080.98.5.10.13 en 9 - 3
9
Slice thickness setting = 0.5 to 24 mm = 0.02" to 0.95", stepless
Types of current, voltag-
es, power consumptions
= see rating plate
9.3 Dimensions VS12F37
Fig. 65: VS12F37, example
The machine is available in different versions. The figure shows an example:
Outer dimensions:
1
Length
= 756 mm = 29.8"
2
Width
= 712 mm = 28"
3
Height
= 546 mm = 21.5"
Installation surface:
4
Length
= 605 mm = 23.8"
5
Width
= 430 mm = 17"
Work area:
6
Length
= 930 mm = 36.6"
7
Width
= 795 mm = 31.3"
Weight
= approx. 52 kg = 114 lb
Blade diameter = 370 mm = 14.6"
Blade speed = 266 rpm
