Operating instructions VS12 /C /F /F-P /W Maintenance
6.080.98.5.10.13 en 8 - 15
8
8.6.3 Attaching the sharpener
WARNING Unprotected blade!
Coming in contact with the sharp blade can lead to serious inju-
ries.
–
Wear cut-proof gloves when cleaning and sharpening.
– Do not clean the blades when operating the machine.
Set slice thickness to "24" or open until stop.
Fig. 56: Attaching the sharpener
Set handwheel marking on sharpener to
"0".
Move carriage to relevant position.
Mount sharpener to gauge plate from
the top.
Fig. 57: Tightening sharpener
Push the sharpener and carriage to-
wards the blade until the adapter con-
tacts the front of the blade guard ring.
Keep the sharpener in this position and
use the star knob to screw it to the
gauge plate.
8.6.4 Sharpening
Wear eye protection!
Hearing protection is recommended.
