Operation Operating instructions VS12 /C /F /F-P /W
6 - 2 6.080.98.5.10.13 en
6
Fig. 23: Slicing the product
The fingers of the right hand hold on to
the product, the thumb is positioned at
the back of the carriage.
Uniformly slide carriage forth and back,
simultaneously apply slight pressure to
product by hand and push towards
blade.
Slices drop on depositing area or are re-
moved from deflector with left hand.
If necessary, re-clamp product holder.
Once the slicing process is completed
set slice thickness to "0".
Switch off machine.
For safe slicing of remnants we recommend the following:
Fig. 24: Insert product ends
Place product end against the back pan-
el of the carriage, making sure that the
original cut surface faces the remnant
holder plate.
For slicing of tied products, first cut-off
tied end by hand.
In order to slice product ends approx. 15
mm and smaller, the product fixation de-
vice needs to be moved behind the rem-
nant holder.
Move the product holder by the hand
grip and position behind
the product.
If the distance between the product holder and the blade is shorter than
60 mm, the product holder is force-guided and cannot be swiveled up-
wards.
6.2 Inserting and slicing product with the VS12F
WARNING Rotating blade!
Cut injuries
–
Do not allow yourself to become distracted. Concentrate on the
task in hand and avoid time pressure.
– Never push product ends towards blade by hand.
